Are you facing following challenges during plastic injection mould design?
- Ability to detect manufacturing defects such as weld lines, air traps etc. and best gate location for plastic injection moulding process
- Ability to set the most effective plastic injection moulding process parameters
- Ability to optimize the runners and cooling layout and predict problems concerning any part of the plastic component creation process
- Shorter model preparation and calculation times
- Complete solution at an optimum cost from filling analysis to warpage calculations and thermal optimization analysis
- Ability to import different types of CAD geometry file formats
- Ability to import or quickly create runner and cooling systems
- Extensive material database covering a wide selection of plastic material grades and suppliers
We have a solution from Hexagon for you addressing all the above-mentioned challenges faced during the plastic injection moulding flow simulation process. VISI Flow is a unique prediction tool, ideal for pre and postproduction analysis and concurrent engineering of injection moulded plastic components.
Following are the key features of VISI Flow addressing all the above-mentioned challenges faced during plastic injection mould design phase:
- Integrated CAD/CAE application
- Unique patented solid meshing technology
- Short model preparation and calculation times
- Accurate filling simulation
- Identification of aesthetic issues
- Multiple moulding variables
- Fibre orientation
- Material database customization
- Warpage prediction
- Thermal analysis
- Cooling layout optimization
- Import of cooling and feeding system
